It can be applied to the construction of expressways, bridge‑road projects, housing construction, subways and other projects. This line shears bar raw materials with a diameter of 10‑50 mm. The distance between the cutting blade and the positioning baffle is adjusted by a lead‑screw mechanism driven by servo motors. Positioning is measured via an encoder, achieving a cutting‑length tolerance of ±2 mm, so rebars of various lengths can be processed.

Meanwhile, the CNC bar‑shearing production line adopts oil‑cylinder pressing for rebars. With large clamping force, the rebars will not rotate during shearing, thus obtaining uniform cut‑off ends.
